Power Supply--Access Power Controller

8 relay lock control outputs fused at 3A per output, each output selectable for FAI, fai-safe, fail-secure, Bus1 or Bus2

4 relay lock control outputs class 2 power limited at 2.5A per output, each output selectable for FAI, fail-safe, fail-secure, Bus1 or Bus2

4 relay lock control outputs fused at 3A per output, each output selectable for FAI, fail-safe, failsecure, Bus1 or Bus2

Panic Device Power Controller - Controlled lock output for 24VDC panic hardware device with high inrush current requirements or a mag lock/electric strike, One 24VDC aux. power output rated @ 0.5 amp, built-in battery charger, encl. 8.5"H x 7.5"W x 3.5"D, Accommodates up to 2 - 12VDC/4AH batteries, 115VAC input. UL Listed (UL294), cUL Listed.

Dual Panic Device Power Controller - Independently or simultaneously controlled lock outputs for two 24VDC panic hardware devices with high inrush current requirements. Programmable 1 to 30 sec. timed lock release, Two follower relay outputs, Two delayed momentary relay outputs, One 12VDC & One 24VDC aux. power outputs rated @ 1 amp each, Fire Alarm disconnect, built-in battery charger, encl: 13.5"H x 13"W x 3.25"D, Accommodates up to 2 - 12VDC/7AH batteries, 115VAC input, UL Listed (UL294), cUL Listed. MEA & CSFM Approved.

MAXIMAL75D: 16 PTC Class 2 power limited outputs, 8 outputs are 12VDC @ 9.5 amp and 8 outputs are 24VDC @ 9.7 amp

MAXIMAL77D: 16 PTC Class 2 power limited outputs, each set of 8 outputs is 24VDC @ 9.7 amp

MAXIMAL55D: 16 PTC power limited outputs, each set of 8 outputs is 12VDC @ 9.5 amp

MAXIMAL33D: 16 PTC Class 2 power limited outputs, each set of 8 outputs are selectable for 12VDC @ 5.5 amp or 24VDC @ 5.7 amp

MAXIMAL75: 8 outputs are 12VDC @ 9.5 amp and 8 outputs are 24VDC @ 9.7 amp

MAXIMAL77: Each set of 8 outputs is 24VDC @ 9.7 amp

MAXIMAL55: Each set of 8 outputs is 12VDC @ 9.5 amp
